High Speed Processing on Large Wafers with Newly Developed On-the-Fly Laser Equipment

In order to be able to manufacture more efficient solar modules, the photovoltaic industry is increasingly switching its production to larger wafer formats. Being able to guarantee the production of these solar cells with an edge length of up to 210 millimeters with consistent quality and cycle rate poses new challenges for equipment manufacturers. A research team at the Fraunhofer Institute for Solar Energy System ISE has now succeeded in implementing a novel system concept, whereby large-format solar cells are continually processed as they move at high speed under the laser scanner. The new system for solar cell processing can laser half a million contact openings per second and has an effective throughput of over 15,000 solar wafers per hour. Visitors to LASER World of PHOTONICS 2022 (April 26-29, Messe München) can learn more about the system concept at the Fraunhofer booth 441 in Hall A6.

© Fraunhofer ISE
The new system concept enables solar cell manufacturers to perform laser processing at the highest speed without having to compromise on structure size or processing area.

The new Fraunhofer ISE concept, on the other hand, is suitable for implementing large-area wafer formats such as M12 and G12, even with high throughput and small structure sizes. At the heart of the new system is the polygon scan technology from project partner MOEWE Optical Solutions GmbH, in which a high-speed mirror wheel moves the laser beam over the sample at over 3,000 kilometers per hour. This is about 20 times faster than the galvanometer scanners commonly used today. "To tap the potential of ultrafast scanners and lasers, we developed sensor technology designed specifically for the new system in order to achieve the required positioning accuracy despite the high speed," says Dr. Fabian Meyer, team leader of Laser System Development at Fraunhofer ISE. With 15,000 solar wafers per hour, the throughput of the new system is significantly higher than the current industry standard of 7000 per hour. In addition, Meyer’s team was able to demonstrate that PERC solar cells processed with the demonstrator system have the same high efficiency as cells produced according to the current industry standard.



Because of the low operating costs of laser processing, the researchers expect significant cost benefits from their high-throughput technology. "The results of the research team therefore make an important contribution to increasing productivity and reducing costs in solar cell production," says Dr. Ralf Preu, division director of Photovoltaic Production Technology at Fraunhofer ISE. "The demonstrated system concept is a groundbreaking development for the improvement of structuring processes in the photovoltaic production chain."

High-Throughput On-the-Fly Laser Processing
